Ladder Type Cable Tray Manufacturers in India | GI ladder type cable tray
SAAR Industry is well-known Ladder Type Cable Tray manufacturers in India, suppliers and exporters in India. We have completed 6+ Years and ISO 9OO1-2O15 certified organization for quality control measures to ensure that all its products are of international quality and satisfy customer needs through design and production of high-quality Ladder Cable Trays that offer safe and organised cable routing systems. we deal in manufacturing, and our products specialise in designing and production of high-quality Ladder Type Cable Trays that are used as safe, and organised cable routing solutions. We are precise, durable and have long service life of our products with modern manufacturing facilities, skilled professional and modern machinery.
About Ladder Type Cable Tray
We combine high quality raw materials, high level of fabrication and heavy load of test to reach high
load bearing capacity, corrosion resistance and pro-long performance. We are an efficient cable management systems partner due to our innovation and customer satisfaction. Our vision is to offer affordable, long term and tailored solutions to address the needs of our clients. Our Ladder Type Cable Trays find extensive application in the power, construction, telecommunication, data centers, renewable energy, and infrastructure development industries.
Types of Ladder Type Cable Tray
- Mild Steel (MS) / Hot Dip Galvanized Ladder Type Cable Tray (HDG): The most widely used, stronger material used in, industrial, heavy-duty.
- Aluminum: It is light and noncorrosive and is suitable in outdoor or specialized conditions.
- Stainless steel (SS 304/316): It is used in marine or corrosive or hygienic environment.
- Fiberglass Reinforced Plastic (FRP): It is non-metallic, corrosion resistant, and is capable of operating in high moisture or chemical environment.
- Powder Coated Ladder Type Cable Tray: Gives an added shield and color personalization.
- GI ladder type cable tray: It is a cable support system that is made of galvanized steel and is used to support heavy cable management and it is very strong, resistant to corrosion and easy to maintain.
- Standard Ladder Tray: Bottom is designed with two side rails that are parallel to each other and perpendicular to the rungs, to enable easy cable tie downs and maximum airflow.
- Single Rail Ladder: Has either a single rail in the middle with the rungs spread on either side which provide a lighter and open construction design with simplified access to cables, commonly applied in commercial jobs.
- Channel Ladder: This is a very rugged, frequently enclosed shape, that serves as a combination of a ladder and a solid-bottom tray to provide greater protection of the cables and yet allow air to pass.
- Heavy Duty Ladder: This will be made with heavier materials and larger side rails to be used in the industries where cabling is of high density.
Technical Specifications of Ladder Type Cable Tray
| Feature | Specification Details |
|---|---|
| Material | Mild Steel (MS), Stainless Steel (SS), or Aluminium |
| Design Structure | Two longitudinal side rails connected by individual transverse members (Rungs) |
| Standard Length | 2500 mm (2.5 Meters) per section (Custom lengths up to 3000 mm available) |
| Width Range | 100 mm to 1200 mm |
| Side Rail Height | 50 mm to 150 mm |
| Sheet Thickness | 1.0 mm to 3.0 mm (16 SWG to 10 SWG) |
| Rung Spacing | 250 mm to 300 mm (Standard interval between rungs) |
| Surface Finish | Hot-Dip Galvanized (HDG), Pre-Galvanized (GP), or Powder Coated |
| Manufacturing Standard | ISO 9001:2015 Certified; compliant with IEC & NEMA standards |
| Accessories | Horizontal/Vertical Bends, Tees, Crosses, Reducers, Coupler Plates, and Hold-down Clamps |
Features of Ladder Type Cable Tray
- High load-bearing capacity for heavy cables
- Excellent ventilation for heat dissipation
- Strong and rigid construction
- Corrosion-resistant coatings available
- Suitable for long-span routing
Benefits of choosing us as Ladder Type Cable Tray suppliers in India
- High Load Capacity: The Cable Trays are Ladder Type Cables, which are robust and can support heavy power cables. These have the ability to support high cable loads.
- Excellent Heat Dissipation: Cables are surrounded by air circulation created by open ladder structure. This will assist in curbing overheating and prolong the life of the electrical cables.
- Good and simple installation and maintenance: Ladder trays have the option of rapid cable laying and easy inspection. It is easy to add or remove cables without interfering with the system. This is saving time and maintenance expense.
- Long lasting and resistant to corrosion: These trays come in galvanized, powder-coated trays, and other finishes. This shields them against rust, dampness, and harsh conditions thus making them have long service life.
- Cost-Effective Solution: Ladder Type Cable Trays minimise the use of conduits and complicated wiring. These are cost-effective in the mega projects and the expansion of the cable in the future.
Applications of Ladder Type Cable Tray
- Factories and Industrial Plants: Meant to hold power and control cables to machines and equipment. These are used to keep the wiring in manufacturing plants in order.
- Commercial Buildings: Fitted in offices, shopping centers, and business centers as power and communication cables. These guarantee proper cable management.
- Infrastructure Projects: Applied in airports, railways, highways and in public utilities as power distribution and signalling cables. These are applicable in massive installations.
- IT Facilities and Data Centers: Familiar with laying network and power cables. Ladder trays enhance air circulation and streamline the cables in data centers.
- Renewable Energy Projects: These are applied in solar and wind power plants to hold power transmission cables. These are constructed to endure the outdoor and hard environmental conditions.
Why choose us as Ladder Type Cable Tray manufacturers in India?
- Experienced Manufacturer: Our experience in manufacturing cable tray is very extensive thus our products are high quality and reliable.
- ISO Certified Standards of Quality: We have stringent inspection and testing of our manufacturing process as per international standards of quality.
- Premium Raw Materials: Our materials have high quality property to guarantee strength, durability, and corrosion resistance.
- Customized Solutions: As required by the customer, we offer cable trays in various shapes and sizes with varying thicknesses and finishes.
SAAR Industry is leading Ladder Type Cable Tray manufacturers in India, suppliers and exporters in India are a necessity in a cable and electrical management system in the contemporary world. These offer high support, maintenance and reliability of power and communication cables over a long period. Our Group of Industries produces high quality Ladder Type Cable Trays, which are of the industry and customer standards. We design our products to be long lasting, safe and workable at any place.
Get in touch with Us to get Ladder Type Cable Tray solutions of high quality. Observe professional advice, low prices, and prompt delivery on your needs. Work with us in order to get good and long term cable management systems.
FAQ's
Ladder trays are constructed of steel of high quality and it comes in galvanized and powder-coated finishes to resist corrosion.
These are applied in industrial facilities, commercial structures, information centers, infrastructure developments, and renewable energy systems.
Yes, These can be made in various sizes with varied thickness and finish as per the requirements of the customer.
Hot-dip galvanized trays are indeed suitable in extreme environments and outdoors.
